OfficeLED P 5000 840 in the group Products / Interior at Nokalux (154631)

OfficeLED P 5000 840

Ljuskurva
Ner CE-markning D-markning F-markning
Delivery time:
1-2 working days
Article nr: 154631
E-number: 7016757

  • Description
  • Interior ceiling fixture or suspended assembly with or without uplight.

    Sheetmetal housing with RAL 9010 textured white paint.
    Plastic endcaps.

    Metallised doubleparabolic anti-glare louvre (SP) with integrated opal diffuser.

    Ceiling version:
    Connection at ends or centre of fixture.
    Fixing with keyhole.

    Pendandt uplight version: As standard with adjustable suspension wire with halogen-free cable 2.4 m with earthed plug. Version available with separated down-/uplight (ST). Dimmable version (TDC) equipped with Dali dimmable driver, push-button control and corridor function.
    Pendant equipped with 5-wire cable.

    Can be fitted with sensor and pull-cord switch.

    AirC:
    Sensorsystems with daylightcontrol that can be programmed via app. The sensor can also
    communicate wirelessly with more sensors. Wireless switches can be integrated in this system.

    Lifespan L80 Ta25 60000h (B50)
    MacAdams 3 SDCM CRI: >80
    Do a simple lighting calculation!
  • Characteristics
  • E-nr: 7016757
    Lumen: 5310
    Power: 49 W
    CCT, Kelvin: 840
    Weight: 3,9
    CC dimensions: 1420
    Width: 101
    Height: 73
    Length: 1498
    Energyclass (LED module): C
    MCB B10A: 15
    MCB B16A: 24
    MCB C10A: 24
    MCB C16A: 40
    Start W: 21
    Time μs: 220
  • Electrical data
  • Light distribution
  • Documents
  • Product sheet

    File light distribution

    Dimensions
