FlatLED 12.2 830

Ljuskurva
Uppner CE-markning D-markning F-markning
Delivery time:
1-2 working days
Article nr: 157101
E-number: 7011557

  • Description
  • Suspended luminaire with up and down lights for use in offices.

    Sheetmetal housing with RAL 9010 textured white paint.
    Silver-grey anti-glare louvre with diffuserplate.

    Supplied with a halogen-free cable (2.2 m), earthed plug and a wiresuspension with a friction lock.
    Two pull-switches for separate activation of up and down lights.
    Dustprotector as standard.

    Sensor
    Integrated sensor that activates the light after detecting movement.

    TD
    Light control with two pull-microswitches.

    Sensor TD
    Light control with two pull-microswitches and an integrated sensor that activates the light after
    detecting movement.

    Actilume
    Philips Actilume system with integrated sensor and light control according to daylight level.

    AirC:
    Sensorsystems with daylightcontrol that can be programmed via app.
    The sensor can also communicate wirelessly with more sensors.
    Wireless switches can be integrated in this system.

    Lifespan: L80 Ta25 70000h (B50)
    MacAdam 3 SDCM CRI >80

    Do a simple lighting calculation!
  • Characteristics
  • E-nr: 7011557
    Lumen: 6130
    Power: 50 W
    CCT, Kelvin: 830
    Weight: 5
    CC dimensions: 1200
    Width: 168
    Height: 39
    Length: 1274
    Energyclass (LED module): E
    MCB B10A: 8
    MCB B16A: 12
    MCB C10A: 12
    MCB C16A: 20
    Start W: 33
    Time μs: 280
  • Electrical data
  • Light distribution
  • Documents
  • Product sheet

    File light distribution

    Dimensions

airc-logo
1-2 working days
