FlatLED in the group Categories / Pendant at Nokalux (157101r)

FlatLED

Ljuskurva
Uppner CE-markning D-markning F-markning
Delivery time:
1-2 working days
Article nr: 157101r
E-number:

Campaign

Campaign:
Quantity:
0
Campaign starts:
Campaign stops:
  • Description
  • Suspended luminaire with up and down lights for use in offices.

    Sheetmetal housing with RAL 9010 textured white paint.
    Silver-grey anti-glare louvre with diffuserplate.

    Supplied with a halogen-free cable (2.2 m), earthed plug and a wiresuspension with a friction lock.
    Two pull-switches for separate activation of up and down lights.
    Dustprotector as standard.

    Sensor
    Integrated sensor that activates the light after detecting movement.

    TD
    Light control with two pull-microswitches.

    Sensor TD
    Light control with two pull-microswitches and an integrated sensor that activates the light after
    detecting movement.

    Actilume
    Philips Actilume system with integrated sensor and light control according to daylight level.

    AirC:
    Sensorsystems with daylightcontrol that can be programmed via app.
    The sensor can also communicate wirelessly with more sensors.
    Wireless switches can be integrated in this system.

    Lifespan: L80 Ta25 70000h (B50)
    MacAdam 3 SDCM CRI >80

    Do a simple lighting calculation!
  • Characteristics
  • E-nr: 7011557, 7011558, 7011559, 7011560, 7011657, 7011658, 7011660, 7011666, 7018042, 7018043
    Lumen: 6130, 6380
    Power: 50 W
    CCT, Kelvin: 830, 840
    CC dimensions: 1200
    Weight: 5
    Width: 168
    Height: 39
    Length: 1274
    Energyclass (LED module): C, D, E
    MCB B10A: 8
    MCB B16A: 12
    MCB C10A: 12
    MCB C16A: 20
    Start W: 33, 37
    Time μs: 275, 280
  • Electrical data
  • Light distribution
  • Documents
  • Product sheet

    File light distribution

    Dimensions

airc-logo
1-2 working days

Accessories

Artiklelist

Show all Show less

Type Article nr Lumen Power File light distribution File light Light calculation Calculation
FlatLED 12.2 830 AirC 157121 6130 50 FlatLED 12.2 830 AirC
FlatLED 12.2 830 Sensor TD 157117 6130 50 FlatLED 12.2 830 Sensor TD
FlatLED 12.2 830 Sensor 157113 6130 50 FlatLED 12.2 830 Sensor
FlatLED 12.2 830 TD 157105 6130 50 FlatLED 12.2 830 TD
FlatLED 12.2 830 157101 6130 50 FlatLED 12.2 830
FlatLED 12.2 840 AirC 157123 6380 50 FlatLED 12.2 840 AirC
FlatLED 12.2 840 Sensor TD 157119 6380 50 FlatLED 12.2 840 Sensor TD
FlatLED 12.2 840 Sensor 157115 6380 50 FlatLED 12.2 840 Sensor
FlatLED 12.2 840 TD 157107 6380 50 FlatLED 12.2 840 TD
FlatLED 12.2 840 157103 6380 50 FlatLED 12.2 840
